Specifications
General
Weight Capacity 400 Lbs
Maximum Speed 5.20 MPH
Operating Range 17.80 Miles
Suspension Front and Rear
Turning Radius 52"
Ground Clearance 1.25" at transaxle; 3.5" at mid-frame
Colors Grey Street, True Blue
Charger Off-board, 3.5A
Battery (2) U1
Dimensions
Width 20.75 Inches
Length 47.00 Inches
Deck to Top of Seat 15"-16.5"
Ground to Top of Seat 22"-23.5"
Weight
Assembled 182.00 Lbs
Base 132 lbs.
Heaviest Piece 132 lbs.
Without Batteries 132 lbs.
Battery (2) U1
Tires
Rear 3"x9" Solid
Front 3"x9 Solid"
Seat
Style Compact, Foldable
Width x Depth 20"x18"
Height from ground 22"-23.5"
Warranty
Frame Lifetime limited on frame
Drive Train 2-year limited on drivetrain
Electronics 2-year limited on electronics
