Specifications
General
Weight Capacity 400 Lbs
Maximum Speed 5.20 MPH
Operating Range 17.40 Miles
Suspension Front and Rear
Turning Radius 40"
Ground Clearance 1.25" at transaxle; 3.25" at mid-frame
Colors Grey Street, True Blue
Charger Off-board, 3.5A
Battery (2) U1
Dimensions
Width 20.75 Inches
Length 46.00 Inches
Deck to Top of Seat 15"-16.5"
Ground to Top of Seat 22"-23.5"
Weight
Assembled 170.00 Lbs
Base 120 lbs.
Heaviest Piece 48 lbs. (rear section)
Without Batteries 120 lbs.
Battery (2) U1
Tires
Rear 3"x9" Solid
Front 3"x8"
Seat
Style Compact, Foldable
Width x Depth 20"x18"
Height from ground 22"-23.5"
Warranty
Frame Lifetime limited on frame
Drive Train 2-year limited on drivetrain
Electronics 2-year limited on electronics
