Specifications
General
Weight Capacity 300 Lbs
Maximum Speed 5.00 MPH
Operating Range 12.00 Miles
Turning Radius 39"
Ground Clearance 3.75” (Under Deck), 2.5" (to Transaxle/ Motor0
Drive Wheels Rear
Colors Blue, Red
Freewheel Mode Yes
Charger Off Board
Controller 90 Amp
Battery 2-22 AH
Electronic Speed Control Yes
Electro-Mechanical Brakes Yes
Dimensions
Width 22.00 Inches
Length 41.50 Inches
Deck to Top of Seat 18” – 20”
Ground to Top of Deck 6″
Ground to Top of Seat 23.5” – 25.5”
Front Axle to Rear Axle 30”
Number of Seat Height Positions 3
Height (ground to top of seat back) 37” – 39”
Size of Increments 1"
Weight
Assembled 125.00 Lbs
Base 93 lbs
Heaviest Piece 44 lbs
Without Batteries 93 lbs
Front Half 44 lbs
Rear Half 28 lbs
Seat w/Arms 21 lbs
Battery 2-22 AH
Tires
Rear 9″
Front 9″
Rear Anti-Tippers 2”
Seat
Style Highback
Color Black Vinyl
Width x Depth 18″ x 16″
Back Height - no headrest 16”
Height from ground 23.5” – 25.5”
Optional Seat Stadium Style
Optional Seat Width x Height 20” x 18”
Optional Seat Color Black Vinyl
Warranty
Frame Lifetime
Drive Train 2 years
Battery 1 year
Electronics 2 years
