Description
The Jazzy 600 ES is designed for users who need a power chair that performs exceptionally well in tight indoor spaces without sacrificing outdoor capability. Pride's Mid-Wheel 6® Technology provides excellent maneuverability, while Active-Trac® ATX Suspension delivers a smoother ride over changing terrain. With one of the tightest turning radii in the Jazzy family, it easily navigates hallways, doorways, shopping aisles, and other confined areas while remaining stable and comfortable outdoors.
Features
- 300 lbs. weight capacity
- Up to 4 mph
- 20.5" turning radius
- Mid-Wheel 6 Technology
- Up to 24.8 miles per charge (300 lbs.)
- Depth adjustable, limited recline high back seat
- In-line joystick mount
- Flip-up, height adjustable foot platform
- Black, flat-free, non-marking tires
- OMNI-Casters (nylon, spherical-shaped casters) on front and rear to prevent wheel hang-ups
- Side-mounted, easily accessible freewheel levers
- Active-Trac ATX Suspension for enhanced performance over more varied terrain
- Easy front access to batteries
- HCPCS Code: Group 2: Standard (K0822/K0823)
Specifications
General
Weight Capacity 300 Lbs
Maximum Speed 4.00 MPH
Operating Range 29.50 Miles
Suspension Active-Trac (ATX) with Mid-wheel 6 Technology
Turning Radius 20.5"
Ground Clearance 2.75"
Drive Wheels Two motor, mid-wheel drive
Colors Cardinal Red
Charger 5A, off-board
Battery 12 volt, NF-22 (2 required)
Electro-Mechanical Brakes Regenerative and electro-mechanical
Dimensions
Width 24.50 Inches
Length 35.50 Inches
Deck to Top of Seat 17.25" - 19.25"
Ground to Top of Seat 21" – 24"
Weight
Assembled 124.00 Lbs
Heaviest Piece 124 lbs.
Seat 18" wide - 51.8 lbs./ 20" wide - 54 lbs.
Battery 12 volt, NF-22 (2 required)
Tires
Rear 6" solid OMNI-Casters
Front 6" solid OMNI-Casters
Middle 14" foam filled
Seat
Width x Depth 18" x 18"-20" / 20" x 18"-20"
Back Height - no headrest 20"W x 20"D
Optional Seat Synergy® Seating: 20"W x 20"D
Warranty
Frame 5-year limited
Drive Train 13-month
Battery 13-month limited
Electronics 13-month limited
