Specifications
General
Weight Capacity 500 Lbs
Maximum Speed 11.00 MPH
Operating Range 34.00 Miles
Turning Radius 76″
Ground Clearance 4″
Drive Wheels Rear
Colors Red & Grey
Freewheel Mode Yes
Charger Off Board
Controller 200 Amp
Battery 75 AH – 100 AH
Electronic Speed Control Yes
Electro-Mechanical Brakes Yes
Dimensions
Width 31.70 Inches
Length 63.00 Inches
Deck to Top of Seat 19.5″
Ground to Top of Deck 7″
Ground to Top of Seat 26.5″
Front Axle to Rear Axle 43.75″
Number of Seat Height Positions 2
Height (ground to top of seat back) 56.5″
Size of Increments 1”
Weight
Assembled 377.00 Lbs
Base 208 lbs.
Heaviest Piece 67 lbs.
Without Batteries 208 lbs.
Seat w/Arms 54 lbs.
Battery 75 AH – 100 AH
Tires
Tire Type Pneumatic
Rear 13″ 6.5″
Front 13″ x 6.5″
Seat
Style Captain’s High-Back
Color Black Vinyl
Width x Depth 20” x 18”
Height from ground 26.5″
Warranty
Frame 5 Years
Drive Train 2 years
Battery 1 year
Electronics 2 years
