Specifications
General
Weight Capacity 300 Lbs
Maximum Speed 4.00 MPH
Operating Range 24.00 Miles
Turning Radius 24″
Ground Clearance 3.25″
Drive Wheels Center
Colors Blue, Red
Freewheel Mode Yes
Charger Off Board
Controller 40 Amp
Battery 2-U1/ up to 50AH
Electronic Speed Control Yes
Electro-Mechanical Brakes Yes
Dimensions
Width 24.00 Inches
Length 39.50 Inches
Ground to Top of Seat 19″ – 21″
Height (ground to top of seat back) 40″ – 42″
Weight
Assembled 179.00 Lbs
Base 97 lbs.
Without Batteries 97 lbs.
Seat w/Arms 40 lbs.
Battery 2-U1/ up to 50AH
Tires
Casters 6″
Seat
Style Captain’s Seat
Color Black Vinyl
Width x Depth 18″ x 18″/20″
Back Height - no headrest 23″
Back Height - with headrest 30.5” – 34.5”
Height from ground 19″ – 21″
Optional Seat Captain’s Chair
Optional Seat Back Height - no headrest 19″ (Optional Seat 2 Back Height (no headrest))
Optional Seat Width x Height 16″, 18″, 20″, or 22″ x 16″, 18″ or 20″
Optional Seat Color Black Vinyl
Warranty
Frame Lifetime
Drive Train 13 months
Battery 1 year
Electronics 13 months
