Specifications
General
Weight Capacity 450 Lbs
Maximum Speed 4.00 MPH
Operating Range 12.00 Miles
Turning Radius 20″
Ground Clearance 3.5″
Drive Wheels Center
Colors Blue, Red
Freewheel Mode Yes
Charger Off Board
Controller 75 Amp
Battery NF22
Electronic Speed Control Yes
Electro-Mechanical Brakes Yes
Dimensions
Width 25.00 Inches
Length 40.00 Inches
Ground to Top of Seat 21.25” – 24.25”
Number of Seat Height Positions 5
Height (ground to top of seat back) 38.25” – 42.75”
Size of Increments 0.5″
Weight
Assembled 226.00 Lbs
Base 101 lbs.
Heaviest Piece 51 lbs.
Without Batteries 101 lbs.
Seat w/Arms 51 lbs.
Battery NF22
Tires
Tire Type Flat Free / Non Marking Solid
Casters 6″
Seat
Style Captain’s Seat
Color Black Vinyl
Width x Depth 18″-24″x18″-20″
Back Height - no headrest 19″
Back Height - with headrest 26.5″-30″
Height from ground 21.25” – 24.25”
Optional Seat Captain’s Chair
Optional Seat Back Height - no headrest 19″ (Optional Seat 2 Back Height (no headrest))
Optional Seat Width x Height 18″-24″x18″-20″
Optional Seat Color Black Vinyl
Warranty
Frame 5 Years
Drive Train 13 months
Battery 1 year
Electronics 13 months
