Specifications
General
Weight Capacity 350 Lbs
Maximum Speed 5.00 MPH
Operating Range 19.00 Miles
Turning Radius 37″
Ground Clearance 3.75″
Drive Wheels Rear
Colors Azure Blue, Crimson Red
Freewheel Mode Yes
Charger Portable 3.5 Amp Off Board
Controller 90 Amp
Battery U1
Electronic Speed Control Yes
Electro-Mechanical Brakes Yes
Dimensions
Width 24.00 Inches
Length 42.25 Inches
Ground to Top of Deck 6.25”
Ground to Top of Seat 22.25″ – 24.30″
Front Axle to Rear Axle 30”
Number of Seat Height Positions 3
Height (ground to top of seat back) 37.5″ – 39.5″
Size of Increments 1”
Weight
Assembled 170.80 Lbs
Base 149.8
Without Batteries 149.8
Battery U1
Tires
Tire Type Solid/Low Profile
Rear 10.75″
Front 9″
Rear Anti-Tippers 3″
Seat
Style Quilted High Back
Color Black
Width x Depth 18″ x 16″
Back Height - no headrest 16″
Height from ground 22.25″ – 24.30″
Optional Seat Stadium Style
Optional Seat Back Height - no headrest 18”
Optional Seat Width x Height 18″x 16”
Optional Seat Color Black
Warranty
Frame Lifetime
Drive Train 2 years
Battery 1 year
Electronics 2 years
