Specifications
General
Weight Capacity 300 Lbs
Maximum Speed 4.00 MPH
Operating Range 18.00 Miles
Turning Radius 37.5"
Ground Clearance 3.5"
Drive Wheels Rear
Colors Red, Blue
Freewheel Mode Yes
Charger Off-board
Controller 50 Amp
Battery 2-12AH
Electronic Speed Control Yes
Electro-Mechanical Brakes Yes
Dimensions
Width 20.00 Inches
Length 41.00 Inches
Deck to Top of Seat 16.5″-18″
Ground to Top of Deck 5″
Ground to Top of Seat 21.75″-23.25″
Front Axle to Rear Axle 31.5″
Number of Seat Height Positions 3
Height (ground to top of seat back) seat 33.75″ – 35.25″
Size of Increments .75″
Weight
Assembled 93.00 Lbs
Base 77 lbs
Heaviest Piece 32 lbs
Without Batteries 77 lbs
Front Half 32 lbs
Rear Half 24 lbs
Seat w/Arms 21 lbs
Battery 2-12AH
Tires
Tire Type Solid, low profile
Rear 8″
Front 7.5″
Rear Anti-Tippers 2"
Seat
Style Stadium Style
Color Gray Vinyl
Width x Depth 17″x14.5″
Back Height - no headrest 14.75″
Height from ground 21.75″-23.25″
Warranty
Frame Lifetime
Drive Train 2 years
Battery 1 year
Electronics 2 years
