Specifications
General
Weight Capacity 300 Lbs
Maximum Speed 4.00 MPH
Operating Range 7.00 Miles
Turning Radius 39"
Ground Clearance 2.5″ (Under Deck)
Drive Wheels Rear
Colors Red
Freewheel Mode Yes
Charger Off Board
Controller 50 Amp
Battery 2-12AH
Electronic Speed Control Yes
Electro-Mechanical Brakes Yes
Dimensions
Length 41.75 Inches
Deck to Top of Seat 15″-17″
Ground to Top of Deck 4″
Ground to Top of Seat 19″ – 21″
Front Axle to Rear Axle 33.5”
Number of Seat Height Positions 3
Height (ground to top of seat back) 31.75″-33.75″
Size of Increments .75"
Weight
Assembled 97.00 Lbs
Base 62 lbs.
Heaviest Piece 28 lbs.
Without Batteries 62 lbs.
Front Half 28 lbs.
Rear Half 20.5 lbs.
Seat w/Arms 13.5 lbs.
Battery 2-12AH
Tires
Rear 8″
Front 8″
Rear Anti-Tippers 2”
Seat
Color Black Vinyl
Width x Depth 16” x 14”
Back Height - no headrest 12.75”
Height from ground 19″ – 21″
Warranty
Frame Lifetime
Drive Train 2 years
Battery 1 year
Electronics 2 years
