Specifications
General
Weight Capacity 300 Lbs
Maximum Speed 4.00 MPH
Operating Range 11.00 Miles
Turning Radius 28.5″
Ground Clearance 2.5″
Drive Wheels Rear
Colors Blue, Red
Freewheel Mode Yes
Charger Off Board
Controller 40 Amp
Battery 22 AH
Electronic Speed Control Yes
Electro-Mechanical Brakes Yes
Dimensions
Width 23.00 Inches
Length 36.00 Inches
Ground to Top of Seat 21.5” – 23.5”
Number of Seat Height Positions 3
Height (ground to top of seat back) 37.5″ – 39.5″
Size of Increments 1”
Weight
Assembled 124.00 Lbs
Base 96 lbs.
Heaviest Piece 34 lbs.
Without Batteries 96 lbs.
Front Half 29 lbs.
Rear Half 33 lbs.
Seat w/Arms 34 lbs.
Battery 22 AH
Tires
Tire Type Flat Free / Non Marking Solid
Rear 9″
Casters 6″
Anti-Tippers 2” (Rear)
Seat
Style Highback
Color Black Vinyl
Width x Depth 17” x 16”
Back Height - no headrest 18″
Back Height - with headrest 30.5” – 34.5”
Height from ground 21.5” – 23.5”
Warranty
Frame 5 Years
Drive Train 13 months
Battery 1 year
Electronics 13 months
