Specifications
General
Weight Capacity 500 Lbs
Maximum Speed 7.00 MPH
Operating Range 29.50 Miles
Turning Radius 67″
Ground Clearance 4″
Drive Wheels Rear
Colors Red, Silver
Freewheel Mode Yes
Charger Off Board
Controller 140 Amp
Battery NF22
Electronic Speed Control Yes
Electro-Mechanical Brakes Yes
Dimensions
Width 24.50 Inches
Length 57.50 Inches
Deck to Top of Seat 18.75″ – 21.75″
Ground to Top of Deck 6.5”
Ground to Top of Seat 25” – 28”
Front Axle to Rear Axle 38.5”
Number of Seat Height Positions 4
Height (ground to top of seat back) 42.5” – 45.5”
Size of Increments 1”
Weight
Assembled 265.00 Lbs
Base 228 lbs.
Without Batteries 228 lbs.
Front Half 68 lbs.
Rear Half 68 lbs.
Seat w/Arms 55 lbs.
Battery NF22
Tires
Tire Type Pneumatic
Rear 13″
Front 13″
Rear Anti-Tippers 3″
Seat
Style Captain’s Seat
Color Black Vinyl
Width x Depth 20” X 17”
Back Height - no headrest 21″
Back Height - with headrest 27.5” – 31.5″
Height from ground 25” – 28”
Warranty
Frame 5 Years
Drive Train 2 years
Battery 1 year
Electronics 13 months
