Specifications
General
Weight Capacity 400 Lbs
Maximum Speed 5.00 MPH
Operating Range 19.00 Miles
Turning Radius 54″
Ground Clearance 4.25″
Drive Wheels Rear
Colors Azure Blue, Crimson Red, Galactic Grey
Freewheel Mode Yes
Charger Portable 3.5 Amp Super Charger Off Board
Controller 90 Amp
Battery 2-U1/ up to 50AH
Electronic Speed Control Yes
Electro-Mechanical Brakes Yes
Dimensions
Width 24.00 Inches
Length 48.00 Inches
Deck to Top of Seat 17″ – 19″
Ground to Top of Deck 6.5”
Ground to Top of Seat 23” – 25”
Front Axle to Rear Axle 35.5”
Number of Seat Height Positions 3
Height (ground to top of seat back) 38″ – 40″
Size of Increments 1”
Weight
Assembled 222.00 Lbs
Battery 2-U1/ up to 50AH
Tires
Tire Type Solid/Low Profile
Rear 10.75″
Front 10.75″
Rear Anti-Tippers 2″
Seat
Style Highback
Color Black
Width x Depth 18″ x 16″
Back Height - no headrest 18″
Height from ground 23” – 25”
Power Elevating Seat Option Pneumatic Rise Seat, Power Elevating Seat – 6″ with Lockout
Optional Seat Stadium Style
Optional Seat Back Height - no headrest 16”
Optional Seat Width x Height 20” x 18”
Optional Seat Color Black
Warranty
Frame Lifetime
Drive Train 2 years
Battery 1 year
Electronics 2 years
